Thermal Inkjet (TIJ) Printer
S-Jet 600 TIJ 2.5 Industrial Digital Ink Jet Printers
- Easy to use, no mess and zero maintenance
- Connect via TCPIP (internet), USB, Ethernet cable, WIFI, Bluetooth
- Create, save, edit & print from your PC using Nicelabel, Bartender etc.
- Use external protocol to communicate & print from client PC, ERP etc...
- Print from printer resident or offlineclient databases Full GS1 data support
- Connect and print data from External Serial Devices (barcode reader, weigh scale, magnetic card reader etc...)
| Print Features & Specification | |
|---|---|
| Function | Specification |
| Print technology | HP TIJ 2.5 |
| Printer variants | Options of 1 to 12 pen printer systems |
| Number of print lines | 1 to 6 lines per pen depending on selected font |
| Print quality/resolution | Up to 600 dpi |
| Print height per pen/cartridge | up to 12.7 mm |
| Maximum height capability | Up to 150 mm |
| Print speed | up to 300 m/min (500ft/min or 5m/s) |
| Throw distance | Up to 8 mm |
| Fonts | Windows true fonts |
| Print types | Texts, logos, images, full range of 1D, 2D barcodes |
| Print features | Counters, real time date and time stamps, user codes, shift codes, lot numbers |
| Label objects orientation, anchoring, justification | |
| Invert, reverse, | |
| Print from residents or remote offline client standard & GS1 databases | |
| Print mode selections | Standard printing mode (external shaft encoder and external product sensor) |
| Simulated continuous printing mode with automatic (software) internally generated shaft encoder and product sensor signals | |
| internal Shaft encoder Standard printing mode with external product sensor | |
| Repeat printing Mode | |
| Track & Trace with camera vision and product reject mechanism printing mode | |
| External Serial Devices printing mode (weighscale, barcoder reader, Magnetic Card Reader etc..) | |
| Windows driver printing mode (remote off line label creation and printing using Nicelabel, Bartender etc..) Via TCP/IP (internet), Ethernet cable or wifi. | |
| External protocol printing mode for printer integration with customer Production IT system such ERP | |
| Ease of Use | |
|---|---|
| Function | Specification |
| User interface | 10.4” capacitive IPS touch screen |
| Languages | English, Spanish, Chinese, French, German, Russian, Polish, Turkish, Arabic, Portu- guese.. Korean, can easily add any other language |
| Security | Multiple password levels and user privileges set up for security purposes |
| Label creation, editing & saving | Easy to use and powerful template design using controller touch screen or offline PC |
| Windows Driver allows off line remote label Creation, editing, saving and printing us- ing Nicelabel or Bartender software installed on client PC | |
| Diagnostics | Printer “health” recording, storage, report creation & display |
| Printer set up and configuration | Icon based Institutive printer configuration |
| Ease of Integration | |
|---|---|
| Function | Specification |
| I/O's | 16 off I/O's 2 x PEC; 2 x shaft encoders; 2 x warning lights; 2 x relays; 2 x cameras; 4 printheads USB; Ethernet, Bluetooth |
| Internet/network connections & communications | Generate labels offline on client PC then print via TCP/IP, Connect via Ethernet cable or wifi |
| Remote printing and factory inte- gration | External protocol for controlling, communicating and printing from remote client pc or production management systems such as ERP via Ethernet cable, TCP/IP, wifi |
| Windows Printer Driver | To allow networking of printer and ability to communicate and print from windows based software apps |
| Nicelabel & Bartender |
Generates and print templates from powerful label generation software such as Nicelabel & Bartender installed in Sellenis controller or offline in customers PC then use Ethernet cable or wifi to send label to Sellenis' printers to be printed in real time via TCP/IP. |
| Connections to external serial de- vices | Connect, receive and print data from external serial devices such as barcode readers, weigh scales, magnetic card readers or any other external serial device using USB or RS232 Use barcode scanner for ease of use, error free data entry to print from offline cus- tomer's database |
| Camera Vision System GS1 Track & Trace |
Connect, receive and send commands to camera vision system such as Cognex camer- as for use with Read, Print, Verify, Reject and generate report for the purpose of Track and Trace implementation In conjunction with camera vision print from remote customer database unique serial number and full GS1 data barcodes |
| Inks | |
| Function | Specification |
|---|---|
| Read & write to cartridge smart card | Automatic recognition of cartridge ink type, ink level and remaining number of prints |
| Ink level & print data display | Automatic real time live display of ink level, used ink, ink remaining and print data |
| Ink range | Solvent based |
| Aqueous/water based | |
| Pigment & dye based | |
| Invisible UV inks UV curing inks |
|
| Black and colours | |
| Substrates | Print on paper, wood, plastics and metals |
